GIGABYTE MB Sc LGA1200 Z590 D, Intel Z590, 4xDDR4, 1xDP

Socket (pätica):Socket 1200; Formát:ATX; Integrovaná grafická karta:Ano (CPU); Chipset:Intel; Typ pamäťového modulu:DDR4; PCI express 16x:1; Integrovaná LAN karta:1; Podpora RAID:1, 5, 10; Rozhranie:USB 2.0, USB 3.1, 3.5mm Jack, LAN, DisplayPort; Ďalšie rozhranie:S/PDIF, M.2.... viac
140.76 EUR bez DPH
Na dotaz
168.91 EUR
ks
Vyberte si zvýhodnené balenie
Množstevné zľavy
Kód: 524212
EAN: 4719331815448
Záruka: 36 Měsíc(ů)
Popis a parametre

GIGABYTE MB Sc LGA1200 Z590 D, Intel Z590, 4xDDR4, 1xDP

Z590 D


Intel® Z590 Ultra Durable Motherboard with Direct 12+1 Phases Digital VRM, Full PCIe 4.0* Design, Extended Thermal Design, PCIe 4.0 M.2, GbE Gaming LAN, 8-ch HD Audio with Audio Caps, RGB FUSION 2.0, Q-Flash Plus



  • Supports 11th and 10th Gen Intel® Core™ Series Processors

  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs

  • Direct 12+1 Phases Digital VRM Solution with Low RDS(on) MOSFETs

  • Shielded Memory Routing for Better Memory Overclocking

  • Enlarged VRM Heatsink with Multi-Cut to increased surface contact

  • Dual Ultra-Fast NVMe PCIe 4.0*/3.0 x4 M.2

  • GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management

  • RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips

  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP

  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

  • * Actual support may vary by CPU.



CPU


LGA1200 package:
11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors
10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors*
* Limited to processors with 4 MB Intel® Smart Cache, Intel® Celeron® G5xx5 family.
L3 cache varies with CPU
(Please refer to "CPU Support List" for more information.)


Chipset


Intel® Z590 Express Chipset


Memory


11th Generation Intel® Core™ i9/i7/i5 processors:
Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz
10th Generation Intel® Core™ i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules
10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® processors:
Support for DDR4 2666/2400/2133 MHz memory modules
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)


Onboard Graphics


Integrated Graphics Processor-Intel® HD Graphics support:
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
(Graphics specifications may vary depending on CPU support.)


Audio


Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
Support for S/PDIF Out


LAN


Realtek® GbE LAN chip (1 Gbit/100 Mbit)


Expansion Slots


1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 4.0 standard.) (Note)
2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
2 x PCI Express x1 slots (PCIEX1_1, PCIEX1_2)
(The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)


Multi-Graphics Technology


Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies


Storage Interface


CPU:
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU) (Note)
Chipset:
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB)
6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
Intel® Optane™ Memory Ready


USB


Chipset:
8 x USB 3.2 Gen 1 ports (6 ports on the back panel, 2 ports available through the internal USB header)
4 x USB 2.0/1.1 ports available through the internal USB headers


Internal I/O Connectors


1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
6 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
2 x Thunderbolt™ add-in card connectors
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button


Back Panel Connectors


1 x PS/2 mouse port
1 x PS/2 Keyboard port
1 x DisplayPort
6 x USB 3.2 Gen 1 ports
1 x RJ-45 port
3 x audio jacks


I/O Controller


iTE® I/O Controller Chip


H/W Monitoring


Voltage detection
Temperature detection
Fan speed detection
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.


BIOS


1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0


Unique Features


Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
RGB Fusion
Smart Backup
System Information Viewer
Support for Q-Flash Plus
Support for Q-Flash
Support for Xpress Install


Bundled Software


Norton® Internet Security (OEM version)
Realtek® 8118 Gaming LAN Bandwidth Control Utility


Operating System


Support for Windows 10 64-bit


Form Factor


ATX Form Factor; 30.5cm x 24.4cm


Note


Supported by 11th Generation processors only.

.
Typ pamäťového modulu
DDR4
Rozhranie
3.5mm Jack
Socket (pätica)
Socket 1200
Formát
ATX
Integrovaná grafická karta
Ano (CPU)
Chipset
Intel
PCI express 16x
1
Integrovaná LAN karta
1
Podpora RAID
5
Ďalšie rozhranie
M.2
