ASUS MB Sc AM4 PRIME A320M-R, AMD A320, 2xDDR4, VGA, mATX

Socket (pätica):Socket AM4; Formát:micro ATX; Integrovaná grafická karta:Ano (CPU); Chipset:AMD; Typ pamäťového modulu:DDR4; PCI express 16x:1; Integrovaná LAN karta:1; Podpora RAID:1, 10; Rozhranie:HDMI, VGA.... viac
54.56 EUR bez DPH
Na dotaz
65.47 EUR
ks
Vyberte si zvýhodnené balenie
Množstevné zľavy
Kód: 417772
EAN: 4712900986068
Záruka: 36 Měsíc(ů)
Popis a parametre

ASUS MB Sc AM4 PRIME A320M-R, AMD A320, 2xDDR4, VGA, mATX

PRIME A320M-R One-Page Spec

Note: The specifications are subject to change without notice.

CPU

AM4 socket for AMD Ryzen™/7th Generation A-series/Athlon™ Processors

Supports CPU up to 8 cores

*For limited CPU only, refer to www.asus.com for the AMD® CPU support list.

Chipset

AMD A320 Chipset

Memory

AMD Ryzen™ Processors

2 x DIMM, Max. 32GB, DDR4 2933*/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory

AMD 7th Generation A-series/Athlon™ Processors

2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory

Dual Channel Memory Architecture

* Hyper DIMM support is subject to the physical characteristics of individual CPUs.

* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

Graphics

Integrated AMD Radeon™ Vega Core/ R Series Graphics/ 7th Generation A-Series APU

Multi-VGA output support : HDMI/RGB ports

- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz

- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz

Maximum shared memory of 2048 MB

Expansion Slots

AMD Ryzen™ 1st Generation Processors

1 x PCIe 3.0/2.0 x16*

AMD Ryzen™ Processors/ 7th Generation A-series/Athlon™ Processors

1 x PCIe 3.0/2.0 x16 (max. at x8 mode)

1 x PCIe 3.0/2.0 x1 slot

* The working speed of the PCIe 3.0/2.0 x16 slot varies by models.

Storage

AMD A320 Chipset

4 x Serial ATA 6.0 Gb/s connectors with RAID 0, RAID 1 and RAID 10 support

LAN

Realtek® RTL8111H Gigabit LAN Controller

Audio

Realtek® ALC 887-VD2 8-Channel High Definition Audio CODEC

*Use a chassis with HD audio module in the front panel to support an 8-channel audio output.

USB

6 x USB 3.1 Gen1 (2 ports at mid-board, 4 ports at back)

6 x USB 2.0/1.1 ports ( 4 ports at mid-board, 2 ports at back)

ASUS Unique Features

Dependable Stability

ASUS 5X PROTECTION II

- ASUS LANGuard: 2.5X higher surge tolerance

- ASUS Overvoltage Protection: World-class circuit-protecting power design

- ASUS DIGI+ VRM: 6 Phase digital power design

- ASUS ESD Guards - Electrostatic discharge protection

- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!

Superb performance

UEFI BIOS

- Most advanced options with fast response time

Easy PC DIY

Safe motherboard mounting

- Component-free areas to minimize damage risk

Q-Design

- ASUS Q-DIMM

- ASUS Q-Slot

UEFI BIOS EZ Mode

- featuring friendly graphics user interface

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

Quiet Thermal Design:

- Stylish Fanless Design: Chipset Heat-sink

- ASUS Fan Xpert

Back Panel I/O Ports

1 x PS/2 keyboard (purple)

1 x PS/2 mouse port (green)

1 x HDMI port

1 x D-Sub port

1 x LAN (RJ-45) port

2 x USB 2.0 ports

4 x USB 3.1 Gen 1 ports

3 x Audio jacks support 8-channel audio output

Internal I/O Connectors

1 x USB 3.1 Gen 1 connector supports additional 2 USB 3.1 Gen 1 ports

2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports

4 x SATA 6Gb/s connectors

1 x 4-pin CPU Fan connector for 4-pin PWM mode

1 x 4-pin Chassis Fan connector for 4-pin PWM mode

1 x Front panel audio connector (AAFP)

1 x System panel connector

1 x 24-pin EATX Power connector

1 x 4-pin ATX 12V Power connector

1 x Speaker connector

1 x COM header

1 x 2-pin Clear CMOS

BIOS

128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, F3 My Favorites, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control, ErP Ready

Manageability

WfM 2.0, DMI 2.0, WOL by PME, PXE

Accessories

2 x Serial ATA 6.0Gb/s cables

1 x I/O shield

1 x User's manual

1 x Supporting DVD

Operating System Support

Windows® 10 (64-bit)

Form Factor

uATX Form Factor 8.5 inch x 7.6 inches ( 21.6 cm x 19.3 cm )

.
Typ pamäťového modulu
DDR4
Rozhranie
VGA
Socket (pätica)
Socket AM4
Formát
micro ATX
Integrovaná grafická karta
Ano (CPU)
Chipset
AMD
PCI express 16x
1
Integrovaná LAN karta
1
Podpora RAID
10
